Generate electricity from the sun.

Photovoltaic (PV) solar panels convert sunlight into electricity. You can use the electricity to power domestic appliances, and export excess energy to the grid. This means you would be contributing to low carbon electricity for all.

As of April 2019, new installations cannot claim feed-in tariff (FIT) payments. However, there is a proposed scheme that would pay a fair rate for any electricity exported to the grid. The price of solar PV has dropped rapidly in the last ten years and in some cases it could be cost-effective with just a fair export rate.

It is possible to charge a large battery using solar PV panels. However, at present this may not be worthwhile in a grid-connected house. Batteries are still quite expensive, plus they have environmental impacts in manufacture and disposal.

If you want to use sunlight to heat water during the summer, solar water heating (solar thermal) is a more efficient option than PV. This means it would take up less roof space, although there may not currently be much difference in cost.

Installing Solar PV panels
Solar PV panels at CAT

Is my home a good site?

A house roof is usually an excellent site, but panels can also be mounted at ground level. You need a site that’s largely free of shade, particularly between spring and autumn. Solar panels perform well if facing anywhere between south-east and south-west, at an angle of 20 to 50 degrees. A PV array that faces due east or west will give about 20% less energy than one facing due south. Roof mounted panels are usually a ‘permitted development’, so you won’t normally need planning permission.

How much electricity could I generate?

The ‘rated output’ or ‘rated capacity’ is a key figure to use when you compare PV systems. This is the peak power in kilowatts (kWp or just kW) that a PV array gives in bright summer sunshine. Domestic PV systems are commonly between 3 and 4 kilowatts, taking up 20 to 30 square metres of roof.

Of course it’s not sunny all the time, and the output of PV panels will drop a little under cloud or on winter days, when the sun is weaker. In average UK weather conditions, you can expect one kilowatt of PV panels to generate between 700 and 900 units (kilowatt-hours, kWh) of electricity per year. So a 3.5kW south-facing domestic system will produce about 3,000kWh per year. Where you live will be a factor – for example Cornwall receives 30% more solar energy than northern Scotland.

How much does a solar PV array cost?

Recent prices show an average of about £1,700 per kilowatt. So a 3.5kW array (about 25 square metres) is likely to cost about £6,000.

Ongoing maintenance costs will be very low because there are no moving parts and the panels should last for decades. The only major part that will require replacement every 10 years or so is the inverter, at a cost of perhaps £500 to £1,000. The inverter converts the low voltage DC output of the panels into the 230 volts needed in your home.

A domestic PV system will be particularly economic if you’re renovating a roof, or building a house from new. PV panels can be used in place of roof tiles, and many of the associated costs (such as scaffolding) will be incurred when roofing anyway.

What’s the payback and savings?

The feed-in tariff (FIT) incentive scheme closed to new installations in April 2019. We don’t yet know what payment may be available under a proposed Smart Export Guarantee (SEG). This would require a suitable type of smart meter that is able to measure exported electricity (which many first generation smart meters cannot do). Once we have more details we’ll update this page and our solar calculator with some estimates.

Most PV panels come with a guarantee that they will still be giving something like 80% of their maximum output after 25 years. So a PV roof is a long term investment but could be worthwhile, especially as electricity prices rise. Payback times for many energy saving measures will be quicker, so these should always be your first steps. And there is still financial support for solar water heating systems.

Generating about 3,000 kWh from solar instead of from a gas-fired power station will save about 1.2 tonnes of carbon dioxide emissions. The energy used during the manufacture of PV panels is far less than they will generate through their lifetime. Even with the UK’s levels of sunshine, PV panels will ‘pay back’ this energy cost in less than three years.

What type of PV panel should I use?

Most panels are made using either monocrystalline or polycrystalline silicon. From a practical perspective, there is very little difference between these two types. The output of crystalline silicon panels decreases very slowly over time. Some other types of solar panels may be cheaper but degrade more quickly, so check the power output warranty.

Polycrystalline panels consist of visible crystals in different shades of blue and are slightly less efficient than monocrystalline panels, which are dark blue or black with no visible crystals. This small efficiency difference just means that a 1kW polycrystalline array will be slightly larger than a 1kW monocrystalline array. Under identical conditions, both arrays will produce roughly the same amount of electricity and cost about the same amount.

How can I find a solar PV installer?

Finding a qualified professional installer who can offer you a good service at a competitive price will be important. As with any big investment it’s well worth finding a few installers to get quotes from to compare.

You can find installers by searching the listings of the Microgeneration Certification Scheme (MCS). All installers have to meet certain standards to be accredited, including signing up for a code of conduct such as the Renewable Energy Consumer Code. Their code is backed by the Trading Standards Institute and covers many issues, including ‘hard sell’ aggressive sales tactics. These schemes have complaints procedures to follow up claims against companies that either mis-sell systems or do poor quality work.

Further information

For some additional details, see our questions and answers section below, and the books we sell. You can also visit us to look at the solar systems we have on display here, or to attend one of our courses.

Related Questions

How long do PV panels last?

The life expectancy of a PV panel is likely to be 30 years or longer though there will likely be some cosmetic physical decay and a decrease in energy output.

Crystalline silicon PV panels should come with a ‘power output warranty’. This typically guarantees they’ll still be producing at least 80% of their initial rated peak output after 20 (or sometimes 25) years. So the output is expected to decrease by an average of less than 1% per year.

Very few panels have been installed for long enough to need replacing because of diminished performance. In the UK, more panels were installed between 2006 and 2008 than in all previous years together. Only a small proportion of all PV panels installed globally are more than 10 years old.

Still good in Switzerland after 20 years

The LEE-TISO testing centre for PV components at the University of Applied Sciences of Southern Switzerland installed Europe’s first grid-connected PV plant, a 10kW roof, in May 1982. They analysed the performance of the panels in 2002 and published the results. The PV plant was installed with 288 monocrystalline modules and an initial nominal plant power raring of 10.7kW, or an average of 37W peak rating per panel.

When the panels were tested in 2002, the average peak output of the panels was 32.9W – only 11% lower than the nominal value in 1982. Between 1983 and 2002 the peak output had only degraded by around 0.5% per year.

The LEE-TISO researchers did observe mechanical degradation of their panels. By 2002, 98% of their modules showed signs of yellowing, and 92% had issues with lamination peeling off. However, as the power ouput shows, the impact of delamination on performance was limited and only one single panel was replaced.

What is the environmental impact of photovoltaic (PV) solar panels?

As with any industrial product there is an environmental impact associated with photovoltaic panels. The main areas of potential concern are:

  • The energy required to produce them, and the fuel for this (see the question on energy payback)
  • Toxic and other potentially harmful materials used or created during manufacture.
  • What happens to them at the end of their lifetime.

It’s important to keep these issues in context. All electronic equipment leads to similar concerns, and whereas many electrical goods are only in use for a few years, most PV panels are expected to last for at least 30 years. Furthermore, PV panels are used to replace other sources of electricity that usually have a much greater environmental impact.

The main component of most PV modules is silicon. This isn’t intrinsically harmful, but the manufacturing process does involve toxic chemicals that need to be carefully controlled and regulated to prevent environmental damage.

Making monocrystalline panels tends to result in more waste, as they’re made from slices of silicon ingots – leaving offcuts. However, the waste can be used to make polycrystalline or multicrystalline PV modules, constructed of ‘mashed up’ silicon. Thin film silicon reduces the volume of material needed by spraying a thin layer of silicon on to a surface, so this has the potential to reduce waste and pollution.

A report by the Silicon Valley Toxics Coalition lists a number of potentially damaging chemicals used in the manufacture of PV cells. There are several different types of PV technology and each of them use different processes to manufacture, but they are some harmful chemicals commonly involved.

  • Crystalline silicon is made using silane gas, the production of which results in waste silicon tetrachloride, which is toxic. It can be recycled into more silane gas but has the potential to cause harm.
  • Sulphur Hexafluoride is used to clean the reactor used in silicon production. If it escaped it would be a very potent greenhouse gas. It can also react with silicon to create a range of other compounds.
  • There are a range of other chemicals used for cleaning the silicon and cells.

Aside from silicon production, electrical connections & wiring can include lead and small amounts of aluminium and silver, although lead-free solder is available. The use of lead-based solder leads to pollution if landfilled or incinerated, so good collection and recycling schemes are important. It’s important to note that the same materials are in most other electronic goods, so we need to develop ways to control them and address potential problems anyway.

Some kinds of PV panel contain cadmium, which is an extremely toxic metal. However, when in the form of cadmium telluride (CdTe) it’s a stable non-metallic substance and is not soluble in water. The melting point of CdTe is 1050 degrees C, so accidental domestic fires would not pose a risk. Industrial fires may reach higher temperatures, but tests have shown that the molten CdTe remains contained in the PV module. It is also worth noting that one NiCd battery contains 2500 times as much cadmium as a thin film CdTe PV module, and the production of 1kWh of electricity in a coal fired power station will emit 360 times more cadmium (in air pollution) than is needed in each CdTe solar module per kWh produced. Cadmium is essentially a waste product, as it is only collected as a by-product of zinc mining and manufacture. So it will still need to be dealt with in some way, whether used in PV modules or not.

It will be many years before most PV panels come to the end of their life, so we do have time to make sure recycling schemes are in place and accessible. PV panels are being phased in to WEEE (waste electrical and electronic equipment) legislation, which governs the disposal of electronic equipment – making the manufacturer responsible for eventual disposal or recycling. Manufacturers and distributors of PV panels have already come together in the PV CYCLE scheme.

What’s the energy and carbon payback time for PV panels?

A PV array operating under normal UK conditions will produce many times more energy over its lifetime than was required for its production. Some mistakenly think that PV panels don’t produce as much energy as they take to manufacture, but this stems from the very early days of the satellite industry, when weight and efficiency was far more important than cost.

Studies looking into this question typically conduct what’s called a life cycle assessment (LCA), often known as “cradle-to-grave analysis”, which looks into all the resources that go into the production, operation and disposal of a PV system. This includes the “embodied energy” used when mining the raw materials and producing the panels as well as the electricity they’ll produce. The energy aspect of the LCA is often expressed in terms of the time the system has to operate in order to produce as much amount of energy (or save as much carbon) as was required during production.

Studies draw different boundaries of what should be included in the analysis. For example should it just be the manufacturing of the panels, or also the structures the panels will be mounted on, or even a share of the total personal energy consumption of every labourer involved in the process. Assumptions about the operating conditions will produce different results – for example if the PV panels are installed in California or in northern Europe.

A study by researchers from the Netherlands and the USA (Fthenakis, Kim and Alsema, 2008) analysed PV production processes based on data from 2004-2006. They find that it took 250kWh of electricity to produce 1m2 of crystalline silicon PV panel. Under typical UK conditions, 1m2 of PV panel will produce around 100kWh electricity per year, so it would take around 2.5 years to “pay back” the energy cost of the panel. PV panels have an expected life of least 25 to 30 years, so even under UK conditions a PV panel will generate many times more energy than was needed to manufacture it.

Calculating carbon payback times introduces additional variables, especially the “carbon cost” of the electricity production replaced/avoided by the PV system: Carbon payback times are shorter in countries where electricity is primarily produced using coal power stations, and longer in countries where grid electricity is already produced by low-carbon technologies. But generally payback times for carbon are similar to those for energy.

A 2006 report by the UK Parliamentary Office for Science and Technology calculated a “carbon footprint” of less than 60 grams per kWh of electricity from PV in the UK (or around 35g per kWh in southern Europe), compared to 10 times as much for fossil fuels. Research by Fthenakis, Kim and Alsema, (2008) suggested that total greenhouse gas emissions for electricity from PV panels is between 20 and 80 grams of carbon dioxide equivalent (CO2e) per kWh (under UK conditions). This is far less than the emissions for electricity from fossil fuel power stations. From just burning the fuel (so not including extraction & delivery), gas-fired power stations will emit around 350 to 500 grams of CO2e per kWh, and for coal it can be as high as 1000g per kWh.

Can I install solar PV panels that look like slates or tiles?

A number of companies produce solar tiles or slates, designed to have similar dimensions to flat slate tiles and so suitable for integration into this type of roofing. However, many of these do not have the visual appearance of actual slate. The tiles could still have a blueish crystalline surface, or be a matt or shiny black or grey.

As these solar tiles will still look different to slates or tiles, they may not be any easier to get planning permission for in situations such as a listed building, national park or conservation area. In those situations it’s necessary to check first with the planning authority. For most homes, any kind of solar roof where the panels either form the roof or are mounted just above it (as most are) will be a ‘permitted development’, so planning permission is not needed.

You might be able to find these solar products by going to the Microgeneration Scheme product listings and searching for solar PV products with the keyword ‘slate’ or ’tile’. Or you may just need to ask local installers to see what they can supply.

Integrated solar roofs

Bear in mind also that many types of solar panel can be fitted as an ‘integrated’ solar roof – with the panels flush to the tiles. If you need to reroof anyway, or are building a new home, putting in an integrated roof will save on tiling costs.

It is important to ensure that any integrated array – whether tiles or panels – has adequate ventilation to avoid overheating. However, even with these ventilation measures, an integrated roof is likely to have an lower output that an equivalent non-integrated roof.

Does a roof-integrated PV array need to be ventilated?

Solar photovoltaic (PV) output will reduce a little when the modules reach high temperatures. As a rule of thumb, you can expect around 0.5% decrease in module output per degree centigrade temperature increase.

This does affect the design of roof arrays – as the modules need to be ventilated to prevent them getting excessively hot. An array that is mounted above an existing roof (a “non-integrated” array) will have a gap behind and at the sides, allowing air to circulate and heat to disperse.

Roof-integrated arrays, including PV slates or tiles but also other integrated systems, will not have this circulation, so the array will be prone to getting hotter and so being a bit less efficient.

There are measures that can help improve performance in integrated arrays. One option is ‘counter-battening’, which involves adding extra battens above the sarking but below the conventional battens (and at right angles to these), as in the image below.

This would of course mean some extra roofing work, including removing all slates on that pitch – not just those being replaced with PV tiles. Even with this extra ventilation, an integrated array will still suffer a little from lower performance than a non-integrated array – so it tends to only be used where it is essential for getting planning permission.

Ventilation of integrated PV
Do I need planning permission to install solar panels?

Roof mounted panels are usually a ‘permitted development’ as long as the panels are flush with the existing roof. This means that in most cases you won’t need to apply for planning permission.

However, for National Parks, Areas of Outstanding Natural Beauty, conservation areas and listed buildings, restrictions may apply and you’d need to check with the relevant body. In these cases it can be easier if panels will not be visible from the road (e.g. if the south-facing roof is to your garden).

If the panels are not flush with a roof you would also need to check and may need to get planning permission. For example if you’re mounting panels on a frame placed on a flat roof, or on the ground.

Can I use solar PV panels to heat water?

This is possible and it could save you some money, but at the moment it often leads to higher overall carbon emissions – so the benefits are complicated!

Electricity produced by a PV array can be diverted to an electric immersion heater to heat water for showers & baths. However, most UK homes use mains gas for heating water, and diverting electricity to replace gas will not reduce carbon emissions as much as exporting the electricity to the grid.

If you only option for heating water is electricity anyway, then the carbon saving factor is not an issue, but you could still compare solar PV with solar water heating. And it’s always good to use PV to power electrical appliances where possible – such as using your washing machine on a sunny day.

Carbon emissions

In the UK, mains electricity is produced from a mix of sources. Coal use is being phased out, but there are still a lot of gas-fired power stations. Overall, one unit of daytime UK grid electricity will cause roughly double the carbon emissions of one unit of heat from a modern gas boiler.

Using about 1000 kWh of PV output per year to heat water instead of using mains gas will save about 200kg of carbon emissions. Sending that 1000 kWh to the grid could save about 400kg carbon emissions, based on the average grid mix during daylight hours.

PV panels will be producing electricity during the middle of the day, when the ‘carbon intensity’ of the grid is usually higher. However, in some parts of the country the picture may be different, so it does get complicated. For example, there is a lot more wind power feeding into the grid in Scotland. You can see local and national grid emissions on the Carbon Intensity website.

Financial Savings

Mains electricity costs three times as much per unit as mains gas and twice as much as LPG, so the financial savings from replacing gas are far smaller than replacing electricity use.

If you qualified for feed-in tariff (FIT) payments you will get paid for your solar electricity whether you export it or not. This is why diverting solar for heating can save you some money. If you are able to divert 1000 units of electricity per year, then you might save about £50 on gas. If the diverter costs £300 then it would take 6 years to recoup the installation cost. Overall savings will depend on the cost and the life of the diverter.

However, now that the feed-in tariff has ended for new installations, the potential savings may look very different. The proposed ‘Smart Export Guarantee’ (SEG) would only pay for electricity that is actually exported to the grid. If you could get a wholesale rate of about 5p per unit for the energy you export, then using it instead to replace gas would not actually save any money because gas costs about 5p per unit. Exporting it to the grid would still reduce carbon emissions, as outlined above. Some modern smart meters can meter exports, but many of them cannot – and it’s not yet clear what sort of export tariffs will be available under the SEG scheme.

Solar Water Heating

A different incentive scheme is due to continue. The Renewable Heat Incentive (RHI) gives money back for solar water heating systems, which are in principle a more efficient way to make hot water.

Using a solar water heating system, you’ll need about 1 square metre (1m²) of panel per person to meet the hot water demand in summer, so maybe 3 to 4m² for a family house. Using PV panels you would need about 3 or 4 times as much roof area to get the same energy output. It would take perhaps half of the daily summer output of a 3.5kW (25m²) PV system to heat a cylinder of water.

Having both PV and solar water heating would make the best use of available roof area. Ideally, we would be integrated these both of these technologies into new-build homes – to maximise the contribution of solar energy and reduce carbon emissions.

How can I pump water using wind or solar power?

A renewable energy technology could be ideal for pumping water where there is no mains electricity available, as a grid connection may be expensive and a diesel generator noisy and polluting.

Sizing a pump

The two main factors to consider when seeking a suitable pump are the flow rate – the amount of water that the pump will deliver, and the head – the height through which it will raise the water. These are related, as increasing the head will decrease the delivered flow. It’s important to minimise bends and other friction losses in pipework, as navigating these will require greater pressure, and as pressure and head are directly related, this effectively means a greater head.

Manufacturers’ technical data sheets will give the performance range of each pump, with graphs showing optimum combinations of flow and head. A pump sized properly to your needs will operate most efficiently. Suction pumps are limited to a depth of a few metres, so to draw water from a well or borehole, you’ll almost certainly need to lower in a submersible pump. Pumping wastewater or sewage necessitates one designed to handle drainage or effluent.

Small electric pumps for circulating water could cost tens of pounds, whilst those for drawing water from a well or borehole supply are likely to be a few hundred pounds. The main cost will be providing power to the pump, particularly when off-grid. Therefore, do first take all appropriate water-saving measures (such as spray-head fittings, mulches on plants to minimise water loss, etc) as these easily pay for themselves in the energy saved by reduced demand.

Off-grid electric pumps

Meeting a year-round water demand with a renewably-powered pump may require a combination of PV panels and a wind turbine, as this will balance energy production over the year. Sunshine and wind are naturally intermittent, so you may need some form of storage. Pumping water up to a tank (with demand then fed by gravity) during sunny or windy periods is more efficient than transferring the energy to batteries. If storing lots of water, you’ll need to balance the costs of a large tank (and supporting structure) against the costs of batteries (and their environmental impact and toxicity). An inexpensive control system can pump when needed, and otherwise divert power to batteries, giving extra backup facility.

The price of a small-scale renewable energy system will depend on the power and the maximum capacity needed. A very rough estimate is around £5 to £10 per installed watt. Siting generating equipment close to the pump minimises the cost and power loss incurred by cabling. As small turbines and PV panels usually produce power at 12 or 24 volts, a low-voltage pump would enable you to do without a costly inverter (for stepping up to 240 volts).

Mechanical pumps

For larger-scale pumping applications, you can avoid the losses in electrical systems by using mechanical power directly. See for example the question on our wind power page about wind pumps, or the question on our hydro power page about hydraulic ram pumps.

Can I power a heat pump with solar PV panels?

It sounds great in principle to heat your house using a heat pump, and get the electricity needed using solar photovoltaic (PV) panels.

However, the UK climate makes this impractical. Very little solar energy is available at the time of the year when your heat demand is greatest. A fairly large 4kW solar PV roof (around 30m2) will produce around 15kWh of electricity per day in May or June, but only 3 or 4 kWh on a typical day in December or January. A heat pump may need about twice as much electricity as this.

A solar PV array can still be a good investment in itself, generating low carbon electricity to use in the home or to export and contribute to decarbonising the grid.

If you live in a rural area, you might have wind or hydro power available to you, which give more energy in winter. However, most homes don’t have a suitable site for these energy sources. In a zero carbon future, we could run many heat pumps using electricity supplied through the grid from only renewable energy sources, such as offshore wind farms and wave & tidal power that generate through winter.

What brand of solar PV panel should I choose?

We’re not able to recommend a particular make or brand of PV panel, as we don’t have the facilities to test and evaluate the thousands of panels that are available. However, see below for some information on the standard tests that are in place.

The tests are concerned with the quality and performance of the modules, not with ethical aspects such as environmental standards and workers’ rights. These can vary depending on where the module was manufactured, and note that modules made in the UK may actually just be assembled from components produced in other countries. Ethical considerations will also involve the other activities and financial investments of a company. For ratings of the ethical and environmental background of some of the main PV manufacturers, see the Ethical Consumer website.

PV panels should have certification to show they comply with the technical standards set out in the ‘BS EN 61215’ standard. This involves tests designed to assess the likely long-term strength and durability of a panel, and how it copes with different weather conditions, temperature changes, and so on. The Microgeneration Certification Scheme (MCS) has an accreditation process to ensure that these tests have been carried out by an independent laboratory. There are also audits to check that ongoing production is to the same standard as for the tested panels.
